TRAWLER YACHT 620 trawlers passagemakers live-aboard

Bruce Roberts-Goodson

EMAIL BRUCE

BUILD FOR LESS WITH BRUCE ROBERTS
Check out what customers have to say about our designs & our service.
PLUS check out the links to the beautiful boats they have built with our help !
CUSTOMER COMMENTS

SAILBOAT PLANS BY MATERIAL
FIBERGLASS PLANS
STEEL - ALUMINUM
WOOD EPOXY PLANS

POWER BOAT PLANS BY MATERIAL
FIBERGLASS PLANS
STEEL & ALUMINUM
WOOD EPOXY PLANS

Gwenda Roberts-Goodson

HOME PAGE

NEW ! SUPER STUDY PLANS ! ANY THREE STUDY PLANS ON DOWNLOAD or on CD
The study plans have lists of materials & equipment etc ... these will be a great help in costing out the completed vessel. Each DOWNLOAD or on CD - YOU CHOOSE DOWNLOAD OR CD. . . contains - ALL the construction drawings of your choices of ANY THREE STUDY PLANS with up to 25 sheets per plan! Lists of materials - Technical information - Numerous construction drawings. You can view & print the drawings in full or in sections. PLEASE INDICATE WHICH STUDY PLANS YOU WANT TO ORDER in the SPECIAL INSTRUCTIONS BOX on the ON-LINE-ORDER-FORM + FREE e-book BUILD YOUR OWN POWERBOAT included on DOWNLOAD or on CD HUNDREDS OF STEP BY STEP BUILDING PHOTOS ARE INCLUDED IN THE PACKAGE. Us $99 - Euro €75 ORDER NOW

Voyager TY 650 NEW CUSTOM TRAWLER
PLANS & FULL SIZE FRAME PATTERNS or FIBERGLASS PLANS & FSP

These trawlers are designed in accordance with Lloyds for category 1 (unrestricted operating / sailing area), which is much better than the EU and other Classification Societies and the CE-A require. Complete stability calculations to USCG offshore requirements are included in the design package. All calculations are also cross referenced against ABS requirements to ensure that the design meets world-wide standards and specifications.

'World girdling Trawler Yacht' With it's displacement hull form this design is an ideal long distance cruiser. This is your opportunity to have your own passage-making 'Voyager' designed and built at an affordable price. Now you can put those pieces together into one boat that you REALLY like ! Consider customizing one of our new designs. Bring us YOUR ideas. We can offer Steel or Aluminum Plans and Cutting files, CUT-TO-SIZE KITS or Part-Built or Complete Boats.

NEW PASSAGEMAKING DESIGNS: This is your opportunity to have your own passagemaker designed and built at an affordable price. Now is your opportunity to put those pieces together into one boat that you REALLY like ! Consider customizing one of our new designs. Bring us YOUR ideas. We can offer Steel or Aluminum Plans and Cutting files, CUT-TO-SIZE KITS or Part-Built or Complete Boats. LARGER VERSIONS AVAILABLE AS CUSTOM DESIGNS.

Thank You Bruce for your advice, I recalled that you were very easy to work with back in the late 70's when I built my Offshore 38. I see that same persona still exists. Thanks you for the advice on boat selection. Regards Glen

L.O.A.	19.90 m	65' 5"
BEAM	5.79 m	19' 0"
DRAFT (Full displacement version)	1.82m	6' 0"
DISPLACEMENT (varies depending on version)	54,432 kg	120,000 lbs
POWER	300 - 500 HP
D/L	349
PRISMATIC	0.65
A/B RATIO	2.68

MANY PHOTOS ( OVER 100 ) OF CONSTRUCTION AND OF Voyager TRAWLER YACHTS IN THE WATER ARE INCLUDED WITH THE STUDY PLANS ON DOWNLOAD or on CD - YOU CHOOSE DOWNLOAD OR CD. . . ... ALSO included FREE our 1,400 PAGE e-book BUILD YOUR OWN TRAWLER

EMAIL BRUCE
If you are interested in this new larger custom design !

NEW AFT CABIN TY 650
This new design was conceived because this is the minimum size of trawler where an aft stateroom and a level salon / aft can be combined to make the perfect 2 stateroom / 2 double guest cabin accommodation.

It is possible to create an aft stateroom in a trawler of shorter length BUT this means it is necessary to raise the aft deck to provide headroom in the aft stateroom with the resulting requirement of stairs from the main salon up to a raised aft deck. This arrangement is often seen in smaller craft but is less than desirable if you can afford the luxury of the perfect layout of the Trawler 650.

For those whose cruising area requires a shallow draft vessel, and then it is possible to reduce the draft to 4 ft – 1.22 m by using twin tunnels.

If you prefer an ‘performance trawler’ that is one that can achieve say speeds in excess of 20 knots then again this is possible but the preferred building material in that case should be either aluminum or fiberglass.

As you can see this new design offers a wealth of possibilities as a long range serious cruising trawler and some versions will be suitable for the addition of sail assist to make extended passages possible while saving fuel under favourable conditions.

NEW
CUSTOM AFT CABIN TY 650

For those that want a fully enclosed flybridge / pilot house here we see another version of this design.

Below we show some of our earlier trawler designs that are now well proven having crossed every ocean and proven very popular with their owners.

Section of MASTER SUITE - SEE all photos of this and other Voyager TY 620's that are included in study plans

SEE MORE ON THE TY 620

From owner of TY 620 "MY BLUE STEEL"

I think the TY620 design is great! Trawler Yacht "MY BLUE STEEL", registered in the UK, departed 1800hours on December 28th, 2009 from Mokpo, Korea. I think the TY620 design is great! Trawler Yacht "MY BLUE STEEL", registered in the UK, departed 1800hours on December 28th, 2009 from Mokpo, Korea, Kind regards, Rod

From the builder:

This was the start of her 2,600 nm trip to the Singapore, with stops planned in the Philippines and Kota Kinabalu, although the boat had sufficient range to complete the trip non-stop. The Owner is very satisfied with the interior and sea trials; max speed about 12.7 knots with twin 235HP John Deere at 2000 rpm and 7.0~7.5 knots with one engine at 2000rpm. Onboard were Mr. Rod Steel as the Owner/Skipper, his partner Angie Sach, Mr. John Holbrook and Mr. Alistair Dow. “MY Blue Steel” arrived in Singapore, where she will be based, on 14^th January 2010 and is available for viewing there by prior arrangement.

I am proud to build Bruce Roberts designs, which I am very impressed with, and thank you for your assistance in marketing GHI Yachts Korea.

As you know, we have built to your design (1) Trawler Yacht 43 (2) Trawler 620 (3) Voyager 495 and (4) three Voyager 388 ( first one to be completed and launched on January 30, 2010). PHOTOS of V388 to be sent on January 2010.

Trawler Yacht 620,
John Deere 235HP x 2 @ 2100rpm - Reduction Gear, ZF

Propeller 4 blade and compact stern seal with cooling sea water

Generator 20kw x 2 Northern light - Bow thruster 15kw

Water maker 50L/hour - Crane 500kg – Swimming Ladder

Windlass Maxwell 3500kg, with 70kg + 50 kg Bruce anchors

Air Conditioning - Marinair

Bulbous bow & fixed bilge stabilization

Cockpit, control console and aluminum alloy hard top

Paint as per awlgrip coating scheme

Raymarine C120 full package for two control stations

VHF & SSB

CE certificate

Delivery 10 months after steel cutting

Cruising off Greenland

SEE MORE ON THE TY 485

Trawler 485
STEEL Kit or CUTTING FILES OR
WOOD EPOXY PLANS & FRAME PATTERNS.

Most of our trawlers will accept a sail plan and there are several options you could use including the junk rig. Here we see a small main combined with a flying jib on this TY 485 owned and built by Branko KRESOJEVIC in Belgrade Yugoslavia.

This Trawler 485 was built in Belgrade and has already motor sailed from Yugoslavia via UK, Iceland, Greenland, Canada, USA to South America.

SEE MORE ON THE TY 520

Voyager TY 520 Kit or Cutting files.
AL & Mel Dow - based in Singapore

Hi Bruce, Sea Crest Marine in Bangkok were excellent to deal with. When we left Bangkok we had a sharp 2 metre wave right on the bow for the first 36 hours, quite the opposite from the big following seas that we experienced bringing Rod Steel’s Trawler Yacht 620 down from Korea. The TY520 handled the waves very well indeed. We had a problem with the Auto Pilot hydraulics and had to hand steer for the whole 36 hours so we would have known if the boat was not performing ! Towards the end of the 36 hours as we closed in on the Malaysia / Thai border the seas swung around about 30 degrees from head on and we were still handling things pretty well. No doubt the boat would be improved with Stabilizers but we always felt safe.

We have power steering and the boat really responds well. I am very happy with the way it manoeuvres. Stats wise we have….Single John Deere 267 Hp and we were cruising at 7+ knots using around 15 litres an hour at 1500 rpm. Very economical. Twin Disc Gearbox and 4 blade prop, Onan 17.5 KVA Gen set, 8000 litres of Fuel giving us arrange of around 3000 miles, Yanmar 40Hp for hydraulics. We have stern and bow thrusters and Lewmar windlass all hydraulic, Raymarine Radar and electronics, 2000 litres fresh water, Coltri Sub Dive compressor,

Happy to share any information with prospective builders and also any advice regarding where to build and with whom in South East Asia. I have attached some pictures of the Sea Crest Pilot House and Engine room. They did an excellent job. We arrived in Singapore just as they were having their National Day celebrations so we got some good pictures! Very Happy to be back in Singapore and Very Happy with the boat Bruce. Regards Al Dow

SEE MORE ON THE TY 55

Voyager TRAWLER YACHT 55
SHAKE-DOWN CRUISE.

Hi guys !
Last week we arrived from a "shake - down " cruise , non-stop, in full sea conditions of 605 miles ..... we had a good weather window and the voyage went by without incidents . Our average cruise speed was 8,7 knots but don't have the fuel consumption as yet ( think will be close to 21 lts/hr) Unfortunately none of the three of us had any experience with trawlers to have a good judgement on her motion but it seem pretty good to me. As I gain more experience and improve my judgment on the boat I will pass it on to you . best regards Caio

SEE NEW HOUSE BOAT version of the Trawler Yacht 620

KIT DESIGNS:

NEW CUSTOM PLANS IN FIBERGLASS OR WOOD EPOXY.

Many of you admire our range of kit designs but you would prefer to build in other materials … Consequently we have had many requests to provide alternative custom plans for building in fiberglass or wood epoxy.

TRAWLER YACHT KIT DESIGNS - FIBERGLASS

To check out the Fiberglass construction techniques that will be reflected in the plans and full size frame patterns … REFER to the BUILD YOUR OWN POWERBOAT … chapters 12 and 13

TRAWLER YACHT KIT DESIGNS – Wood Epoxy

To check out the Wood Epoxy techniques that will be reflected in the plans and full size frame patterns … REFER to the BUILD YOUR OWN POWERBOAT … chapter 14

TY 620 Version A ... built in Florida. Just got off the phone Butch the owner of the boat regarding inclining of the TY620. After tweaking the props a bit they are getting 11.8 knots in a full-load condition..!! The installed engines: Perkins 220C 200hp @ 2500 rpm, 2.5:1 gears, final prop: 29 dia x 20 pitch. It sounds as if all are pleased, Hal Whitacre

Hi Bruce . I just wanted too drop you a line and tell you that I went to see your 62 ft trawler "Sorcery" is in the water now and is a beautiful yacht . I met Mr Ralph Elliot ( BUTCH) and his lovely wife and was invited aboard for a look around. Beautiful. Butch and his wife Janice were very nice inviting us aboard.....Thank you Harold Metcalf

This full displacement world girdling trawler yacht is available with FULL WIDTH SALON or as REGULAR SIDE DECKS VERSION Cutting files available or delivered as a steel or aluminum pre-cut package. The Voyager TY 620 is available as a kit in either aluminum or steel. ... FIRST TWENTY SOLD ... If you are interested in a trawler yacht of this size and style now is the time to join in the design process for YOUR version of this vessel. Options include Steel construction, Semi-displacement or full displacement hull, single or twin engines.

There is generous room available to provide accommodation for two couples plus all the facilities expected by today's cruising yachtsman. Trans-ocean capabilities are a feature of this design

From TY 620 builder :
Hi, By the way, the TY 620 - 62 foot trawler yacht of Bruce's design that we are currently building is coming along very well. Just received the drawings ( for TY 620 ) and we are impressed by the amount of detail on these. We have made copies and have our guys studying them. We find these help the guys on the floor to understand the assembly process and things go much quicker. The quality of the kit parts are the best we have ever seen, and as a result, we are saving time in the build. At present, we have 9 welders/fitters working on the boat in three teams. We have almost all of the plate hung in place and tacked up. We anticipate the seam welding will start within a few weeks as there are some details to attend to. But we must say again, that we are very happy with the kit quality. Brian
From another TY 620 builder:
Hi Bruce, Well we're coming along fine with our project. I'm amazed at how straight forward has been. We are having a lot of fun. My employees are anxious to come to work each day as they enjoy the progress as much as I. Thanks for your help, Lee

Lee Simpson's comments to others
"As we worked, more and more respect came to Bruce Roberts for his designs. Things that made no sense came to understanding as we flowed through the process"

Lee Simpson who is building a TY 620 B from our kit writes :

Hi Bruce, Sorry for not writing sooner. We are really enjoying the project. I have a friend that comes to work on the boat in the evening just for the relaxation. We are almost finished welding the hull. We will build the house and pilothouse on a gig on the ground.

I must remove for transport and feel there are benefits to building on the ground. I will lift into place before moving to make sure everything fits. We are making some changes from the original layout to better fit my needs. We've traded the amidships stateroom for a good sized head, pantry and shop/mechanical room. I will install all plumbing, electrical, day-tank, fuel management and heating in this room.

I've moved the engine in place and plan to build a box similar to a sound shield on a generator around the main engine. Quiet is important to me. All tanks are in place. I plan a transom door to the lazarette from the swim step, through the engine room and into the mechanical room. hope to get my office gal to add more photos soon. Regards, Lee

Bruce, I had reply from RYA on plan evaluations. They have been very quick and say they have no concerns about suitability for RDOWNLOAD or on CD - YOU CHOOSE DOWNLOAD OR CD. . .
design Category A. Nice compliment on the quality of your plan information. Everything seems to be OK. They used Naval Architecture Services LTD in Hampshire. LR SSC service group G6 (unrestricted yacht) .

Hi Well, the day finally arrived, the kit is here and on our shop floor. The steel looks great, we are starting to sort it into piles of the frames and associated pieces. I think the guys in Holland did an excellent job of cutting as the edges of the plates are very clean and sharp with almost no bevel. This last point is important, as we find with plasma cut kits, if there is any bevel on the edges it tends to add up and compound errors where multiple parts fit together. So, we are anticipating no problems at this stage. Hope you enjoyed the pictures Bruce (our Bruce) sent you, we will send more as we start assembling the kit. We actually made good progress on Friday and managed to build most of the building frames as well as all of the jigs. We are altering the building frame a bit to allow us to set the jigs on the floor as we are limited in height. As it is we will have to build the mast in a way that it can be bolted on after the boat is out of the building. Yes, everything looks fine and we are sure the kit will assemble fast. Sincerely, Brian

Hi Hal, We have bounced back and forth between DC and Hydraulic thruster' s and have finally decided on hydraulic mainly because we would need a 48 Volt thruster and that meant 12v, 24v, & 48v DC and we just think we would rather have one dc voltage (12V). We had sized the generator for hydraulic anyway so it just makes sense.

We think we will use two 2500 watt inverters and split the loads again to stay with 12 volts DC only. I want to thank you for working so closely through the construction. He will be complete with the mechanical and exterior
within a month and my wife and I will retire in April and work on the interior full time. I am anticipating that work to take 3 to 4 months which is longer than it took to do all the rest. Janet and I are very impressed with your design and would highly recommend both of you to anyone who asks.

We will continue to send pictures and updates as we begin our part of the project.
Thanks again. Ralph E. Elliott III (Butch)
